ONLINE AUCTION SALE - CNC & CONVENTIONAL MACHINE TOOLS (170744)
Auction details
| Sales Starts | 5 May 2025 @ 09:00 |
|---|---|
| Sales Ends | 10 Jun 2025 @ 13:00 |
| Auction Catalogue |
Description
On behalf of various vendors and removed for convenience of sale
CNC & CONVENTIONAL MACHINE TOOLS & ENGINEERING EQUIPMENT
CNC LATHES: 2 x CITIZEN B12 Sliding Head c/w IMECA Boss 325 Barfeed.Fanuc (1995). COLCHESTER CNC2000 x 1250mm.Fanuc 0-T. (1996). COLCHESTER Tornado 220M. Fanuc 21i-TB. (2013). HURCO TM8. WinMax. (2005 & 2008). COLCHESTER Multiturn 4000 x 3M. Fanuc 0i-TC. (2005). COLCHESTER Combi K4 x 1200mm. Fanuc 2010i-T. (2002). COLCHESTER Triumph Electronic GE-Fanuc 20T. (1997). AJAX Victor TNS1A. Fanuc OT. (1985). XYZ VL355x 1000mm (2004). XYZ SLX355 x 1000mm.(2010). XYZ 200TC Siemens 810D. (2006). HARRISON Alpha 550S x 300mm.GE-Fanuc (2000). MORI SEIKI NL2500SY x 700mm c/w Barfeed. Live Tooling.MSX-850BM MAPPS III. Requires Turret Repair. (2007). HARDINGE Cobra 42 c/w Barfeed. GE-Fanuc 21TB. CINCINNATI HAWK TC-150. Fanuc 21i-T (2001).
CNC VMC's: 2 x HAAS TM3P's (2012 & 2015). XYZ VMC1010. Siemens 810D. (2007). HURCO VM2. WinMax. (2006). HURCO Hawk 2U CNC Mill c/w UltiPath Control. CINCINNATI Arrow 750 Series 2. Fanuc 18i-M (1999). CINCINNATI Dart 500. Fanuc 21i-M. (2004).
CONVENTIONAL MACHINES: DEAN SMITH & GRACE 1609CT Surfacing/Boring DEAN SMITH & GRACE 1307 GB. 2 x DEAN SMITH & GRACE Type 21 x 96'' GB. DEAN SMITH & GRACE Type 21 x 72'' GB. DEAN SMITH & GRACE 1910 x 40'' SB (1982). DEAN SMITH & GRACE 1910 x 80'' GB (1985). 2 x COLCHESTER Mastiff 1400 x 80'' GB. COLCHESTER Triumph VS2500 x 50'' SB. SWIFT 16V5 x 80'' GB. WARD 7D & 7DS Capstan & Turret Lathes. HERBERT 2D Capstan. Small Centre lathes inc. ELITE LUNAN, SMART & BROWN VSL & HARRISON 12'' x 24''. JONES & SHIPMAN 1310 Univ. Grinder. 5 x BRIDGEPORT Turret Mills c/w DRO. AJAX AJT1 Turret Mill c/w Slotting. SEMCO LC-50RS c/w DRO. VIKING VM4VS Turret Mill c/w DRO. ELLIOTT 618 Hyd. Surface Grinder c/w Magnetic Chuck. MYFORD MG12 Cyl Grinder c/w Int. Att. BUTLER 8'' Slotter. STARTRITE 24-V-10 & Volant 24 Vertical Bandsaws. ARCHDALE 3'6'' Radial Drill. ASQUITH ARCHDALE 4'6'' Radial Drill. PROMACH UE-250 Horizontal Bandsaw 10'' Capacity. 2 x P.J. HARE AM300 Pneumatic Presses. EPCO & OMEGA H Frame Hydraulic Presses. GARDNER DENVER VS80-7.5 EANA Screw Compressor (2005)
Buyers Premium 18%
Collection Details
All lots can be loaded free of charge by machinebidder staff to flat bed trailers. ALL LOTS MUST BE COLLECTED NO LATER THAN MONDAY 23rd JUNE, 2025.
Viewing Details
All lots can be inspected strictly by appointment with machinebidder in Oldham, Greater Manchester. Tel: 0161 345 3000. All visitors will need to wear Personal Preventative Equipment (PPE). No minors are allowed on site.
Notice To Purchasers
If you are purchasing the equipment with the intention of exporting from the UK you must comply with all the necessary UK export conditions associated with this type of equipment. In certain instances Export Licenses will be required and it is the buyer’s responsibility to make the necessary enquiries prior to bidding. Please note under no circumstances must the goods be used to support equipment for the armed or internal security forces of Countries subject to UN, EU or OSCE arms embargo.
Available Lots
Lots 1-25 of 65
Lot 1: CITIZEN B12 Sliding Head CNC Lathe with Imeca Barfeed. Year 1995
Maximum machining dia. 12mm. Maximum machining length 135mm. Maximum drilled hole dia. 6mm. Maximum dia. for tapping M6. Spindle thro’ hole dia. 14mm. Spindle speeds 100 – 12,000 rpm. Spindle collet chuck FC096-M. Guide bushing WFG541-M. Drill chuck ...
Lot 6: HURCO TM8 CNC Lathe with MAX Control. Year 2005
Maximum swing 525mm dia. Maximum Cutting Diameter 356mm. Maximum Cutting Length 483mm.Bar capacity 51mm.10 station turret. Spindle speed 4,800 rpm. Spindle nose A2-6. Spindle power 16 kW. X travel 203mm. Z travel 508mm. Tailstock. Toolsetter. Swarf conveyor. ...
Lot 9: AJAX-VICTOR TNS1A CNC Lathe with Fanuc OT Control. Year 1985
Swing over bed 420 mm. Swing over cross-slide 300 mm. Distance between centres 395 mm X/Z travels 210/275mm. Spindle speed 6000 rpm. 12 station turret. Tailstock.Fanuc 10T Control. Tooling. Serial No. NJ-0029. Year 1985.
Lot 12: XYZ 200TC CNC Lathe with Siemens 810D Control. Year 2006
Maximum swing 420mm. Maximum turned dia. 200mm. Maximum turned length 550mm. Spindle bore 62mm. Bar capacity 52mm. Spindle speed 4800 rpm. 12 station turret (VDI). Spindle power 14.9kW. Fitted with Hydraulic 200mm dia. 3 jaw chuck. Tool Setting Arm. ...
Lot 22: DEAN SMITH & GRACE 1609 CT Surfacing & Boring Lathe. Year 1973
Swing over bed 16''. Cross sliding turret & tooling. 310mm dia. 3 jaw Chuck. Sliding Chuck Guard. Coolant. Serial No. 3980-10-73. Year 1973
Lot 23: DEAN SMITH & GRACE 13-1 x 42'' Gap Bed Centre Lathe
Swing over bed 13”. Swing over cross slide 7”. Spindle bore 1.5/8”.Distance Between Centres 42”. Speed range 40 - 2240 rpm. Tailstock Taper 3MT. Drilling Attachment. 4 way toolpost. Travelling chuck guard.
Lot 25: DEAN SMITH & GRACE Type 21 x 96 Gap Bed Centre Lathe - Requires electrical repair
Swing over bed 21''. Swing over cross slide 13''. Distance between centres 96''. Spindle speeds 7.5-600 rpm. Spindle dia. 3.1/2''. Motor 12.5 HP . Fitted with 400mm dia. 3 jaw chuck. 560mm dia. 4 jaw chuck. 4 way toolpost. Tailstock. Acurite DRO. Dual ...
Lot 28: DEAN SMITH & GRACE Type 1910 x 80'' Gap Bed Centre Lathe. Year 1985
Swing over bed 495mm. Swing over cross slide 267mm. Swing in gap 737mm Width of gap in front of spindle nose 286mm. Width across bed shears 445mm. Distance between centres 2032mm. Spindle nose D1-8”. Spindle speeds 8-1120 rpm. Spindle bore 81mm. Spindle ...
Lot 29: DEAN SMITH & GRACE Type 1910 x 40'' Straight Bed Centre Lathe. Year 1986
Swing over bed 495mm. Swing over cross slide 267mm. Swing in gap 737mm Width of gap in front of spindle nose 286mm. Width across bed shears 445mm. Distance between centres 1016mm. Spindle nose D1-8”. Spindle speeds 8-1120 rpm. Spindle bore 81mm. Spindle ...
Lot 2: CITIZEN B12 Sliding Head CNC Lathe with Imeca Barfeed. Year 1997
Maximum machining dia. 12mm. Maximum machining length 135mm. Maximum drilled hole dia. 6mm. Maximum dia. for tapping M6. Spindle thro’ hole dia. 14mm. Spindle speeds 100 – 12,000 rpm. Spindle collet chuck FC096-M. Guide bushing WFG541-M. Drill chuck ...
Lot 3: COLCHESTER 2000 CNC Flat Bed Lathe with Fanuc O-T Control. Year 1992
Swing over bed 400mm. Swing over cross slide 246mm. Distance between centres 1250mm. 8 station duplomatic turret. Spindle speeds 6-2750 rpm. Selection of Chuck jaws & tooling as lotted
Lot 16: MORI SEIKI NL2500SY x 700mm Multi Tasking CNC Lathe. Sub spindle. Live Tooling. Y Axis. MSX-850BM MAPPS III Control. Year 2007. (Needs a Turret repair)
Main spindle: Spindle nose A2-8. Maximum turning dia. 366mm. Spindle speeds 4000 rpm. C Axis indexing 0.001°. Maximum bar capacity 80mm. Spindle power 18.5kW. Sub Spindle: Spindle nose A2-5. Maximum turning dia. 190mm. Spindle speeds 6000 rpm. C Axis ...
Lot 18: HAAS TM3P Vertical Machining Centre with Haas Control. Year 2012
Table Size 368 x 1467mm. Travels X/Y/Z 1016 x 508 x 406mm. Maximum workpiece weight 454Kg. Maximum cutting feedrate 10.2m/minute. Rapid feedrates 10.2m/minute. Min – max height under spindle: 102 – 508mm. Spindle motor power 5.6kW. Spindle speed 6000rpm. ...
Lot 19: HAAS TM3P Vertical Machining Centre with Haas Control. Year 2015
Table Size 368 x 1467mm. Travels X/Y/Z 1016 x 508 x 406mm. Maximum workpiece weight 454Kg. Maximum cutting feedrate 10.2m/minute. Rapid feedrates 10.2m/minute. Min – max height under spindle: 102 – 508mm. Spindle motor power 5.6kW. Spindle speed 6000rpm. ...
Lot 20: CINCINNATI Arrow 750 Series 2 Vertical Machining Centre with Fanuc 18i-M Control. Year 1999.
Table size 950mm x 520mm. X/Y/Z travels 762mm/510mm/510mm. Spindle Taper BT40. Spindle Speed 60 - 6000rpm. 21 Position Auto Tool Changer. Spindle tooling as lotted.
Lot 24: DEAN SMITH & GRACE Type 21 x 72'' Gap Bed Centre Lathe
Swing over Bed 21” . Swing in Gap 34” Swing over saddle 13’’. Distance between centres 72”. Spindle speeds. Spindle bore 3 5/8”. 4 way toolpost. Coolant pump.
Lot 27: DEAN SMITH & GRACE Type 1910 x 100'' Gap Bed Centre Lathe
Swing over bed 19''. Swing over cross slide 10''. Distance Between Centres. Swing in gap 32''. Distance between centres 100''. Spindle nose D1-8”. Spindle speeds 8-1120 rpm. Spindle bore 3.3/16''. Spindle power 11.25 kW. Tailstock quill dia.3''. Tailstock ...
Lot 8: COLCHESTER Triumph Electronic CNC Lathe with GE Fanuc 20-T Control. Year 1997
Maximum machining dia. 12mm. Maximum machining length 135mm. Maximum drilled hole dia. 6mm. Maximum dia. for tapping M6. Spindle thro’ hole dia. 14mm. Spindle speeds 100 – 12,000 rpm. Spindle collet chuck FC096-M. Guide bushing WFG541-M. Drill chuck ...
Lot 11: XYZ SLX355 x 1000mm CNC Lathe. Year 2010
Distance Between Centres 1000mm. Swing over Cross slide 225mm. Swing over Bed 360mm. Spindle Bore 52mm. Spindle Speeds 50 – 4000 rev/min. Spindle Motor 5.75Kw. Quick Change Tool Post. Tailstock MT4. Tailstock Dia 75mm. Tailstock Travel 160mm.
Lot 36: HERBERT 2D Capstan Lathe
Maximum swing over bed 9''. Swing over cross slide 7.5/8''. Spindle speeds 50-2550 rpm. Bar capacity 1.11/16''. Fitted with collett chuck & collets as lotted. Turret Toolholders. 4 way toolpost. Rear toolpost.
Lot 38: SMART & BROWN 1024 Mark II VSL 11'' x 24'' Precision Toolroom Centre Lathe
Swing over bed 11''. Swing over 6.1/4''. Distance between centres 24''. Spindle speeds 40-2500 rpm (steplessly variable). Spindle nose 4'' DI Camlock. Spindle bore 1.1/4''. Tailstock taper 3MT. Main motor 3HP. Machine dimensions L x W x H 65'' x 31''. ...
