Single Beam KONE Hoist Type Overhead Crane. 3tonne Capacity.

Year of Manufacture 2017

24ft span from centre wheel to centre wheel
Total length 25ft
Total width 10ft
Complete with 10 x Steel Stanchions and Rail

Swing over bed 1270mm. Swing over saddle 1000mm. Maximum turning diameter 1100mm. Maximum turning length 960mm. Maximum workpiece weight (incl. chuck) 2,200kg. Spindle nose 702-4-NO.15. Spindle max power 65 / 55 / 45kW. Spindle max torque 7,552Nm. Spindle speed maximum 850rpm. Integral box guideway construction. X axis travel 580mm. Z axis travel 1,000mm. C axis travel 360deg. X axis rapid traverse 20m/min. Z axis rapid traverse 20m/min. C axis rapid traverse 14r/min. Type BMT85P. Number of stations 12. OD tool size 32mm square. Boring bar size 80mm diameter. Rotary tool power 7.5/11.0kW. Rotary tool speed 3000rpm. Rotary tool collet size ER50 (6-32mm diameter). Power requirements 98.77kVA.
Additional Accessories
Swarf Conveyor MH500 type (rear exit). Swarf bin. FSE 70 bar NOP pump upgrade for switchable duty 3 pressures: 20, 40 and 70 bar (back pressure) via M code. Coolant chiller. Operator working platform. Coolant wash gun. Renishaw OLP40 inspection probe. Filtermist FX7002F oil mist separator with F Monitor 2.
HC40G Samchully Closed Centre Chuck including 1 set of hard jaws & 1 set of soft jaws. 2 off Face type toolholder (R78935). 2 off Cross type toolholder (R78756A).
Compete with a selection of 8 x unused live tooling
Dimensions L x W x H 2830mm x 3305mm x 4012mm. Weight 22,550kg.
550 Cutting Hours

Swing over bed 660mm. Swing over cross slide 480mm. Maximum turning dia. 500mm. Maximum turning length 2315m. X/Z travel 250 +25mm/2250mm. Rapids X/Z 12/15m/min. Feed rates X/Z 0.001mm/500mm/min. Spindle nose A2-11. Spindle speeds (Geared) Low to 625 rpm (High) to 2500 rpm. Spindle Motor Power (continuous) 22kW. Spindle Motor Power (30 minutes) 26kW. Bar capacity 116mm. Fitted with 385mm dia. 3 jaw chuck. 12 station turret. 2 x Fixed steadies 210mm dia & 410mm dia. capacity. Tailstock dia/stroke 110mm/100mm. Tailstock Taper No.5MT.  Turret  tooling. Oil Cooler. Transformer. Swarf Conveyor. Fanuc Series 0i-TD Control. Machine Manuals. Machine dimensions L x W x H 5924mm (6824mm with swarf conveyor) x 2130mm x 2235mm high. Approximate weight 13,700 kg.

Maximum machining dia. 284mm. Maximum swing over slideway covers 457mm. Travel X/Z  153mm/406mm. Rapids X/Z 30m/min. Spindle speeds 5000rpm. 12 station turret. Tailstock taper 4MT. Coolant capacity 125 litre. Machine complete with 3 jaw powered chuck. Collet Chuck. Assortment of Collets. Toolholders. Siemens Sinumerik 810D Control.Machine dimensions L x W x H 1998mm x 1650mm x 1881mm. Approximate weight 4950 kg

Maximum swing 420mm. Maximum turned dia. 200mm. Maximum turned length 550mm. Spindle bore 62mm. Bar capacity 52mm. Spindle speed 4800 rpm. 12 station turret (VDI). Spindle power 14.9kW. Fitted with Hydraulic 200mm dia. 3 jaw chuck. Tool Setting Arm. Swarf Conveyor. Remote Electronic Handwheel. Multifeed Barfeed. Hydraulic Tailstock. Siemens 810D CNC Control. Weight 4100kg

Table Size 368 x 1467mm. Travels X/Y/Z 1016 x 508 x 406mm. Maximum workpiece weight 454Kg. Maximum cutting feedrate 10.2m/minute. Rapid feedrates 10.2m/minute. Min – max height under spindle: 102 – 508mm. Spindle motor power 5.6kW. Spindle speed 6000rpm. Maximum tool diameter 89mm. Maximum tool weight 5.4Kg. Tool change capacity 10 Stations. Tool change time (chip to chip) 6.5 Seconds. Tool Size BT40. Current Software Version M18.23A. Compensation tables. Intuitive Programming Systems. Rigid Tapping. Spindle Hours 3970. Machine dimensions L x W x H 3470 x 2457 x 2616mm
Weight 2800Kg

Table size 610 x 370mm. T slot size 16mm. Max loading capacity 320Kg. Travels X/Y/Z 560/400/500mm. Distance from spindle nose to working table surface 100 – 600mm. Distance from spindle centre to main column 440mm. Spindle taper BT40. Spindle Speed 60 – 8000RPM. Feed rate X/Y/Z 1 – 10000mm/min. Rapid traverse rate X/Y/Z 20000mm/min. Tool magazine capacity 16. Max tool weight 8Kg. Spindle drive motor 10HP. Coolant 1/2Hp. Complete with FX4002 Filtermist. Dimensions 2400 x 1900 x 2450mm. Approx weight 2700Kg.

*MACHINE REQUIRES NEW GLASS SAFETY SCREEN* Table size 1200mm x 450mm. X/Y/Z travels 1010mm/500mm/520mm. Table loading 850kgs. Spindle Centre to column 625mm. Min/Max Spindle to Table 200mm/700mm. Min/Max Column front to Table Centre 345/905mm. Spindle speeds 60-8000 rpm. Spindle taper BT40. Spindle motor 11.18 kW. Feeds X/Y/Z to 24m/min. Rapids 24m/min. 20 Station ATC. Machine dimensions L x W x H. 3000mm x 2440mm x 2600mm. Approx Weight. 6200kgs.

Axis Travel (X/Y/Z) 600mm/400mm/350mm. Table Size 830mm x 450mm. Maximum Load 300kgs. Spindle Speed 20,000RPM. Spindle Taper HSK-A50. Tool Magazine Capacity 24 Tools. Rapid Feed Rate (X/Y/Z) 15m/min. Positioning Accuracy 0.005mm (X/Y/Z). Machine dimensions (L x W x H) 2590mm x 1690mm x 2370mm. Approx Weight 5800kgs.

Swing over bed 570mm. Turning dia. 420mm. Maximum turning length 650mm. Spindle speeds 3500 rpm. Machine complete 3 jaw powered chuck. 10 station turret. Tailstock. Swarf conveyor. Swarf Bin. Toolsetter. Fanuc 21i-T Control.

2 x 205mm dia Chucks. 8 Tool Turrets. Spindle Speeds 3500rpm. Max. Turning Dia. 300mm. Max. Turning Length 200mm. Serial No: 2SP80170. Machine Dimensions L x W x H 4000mm x 3000mm x 2200mm. Approx Weight. 6500kgs.

Spindle taper 40 ISO. X/Y/Z travels 2540mm/815mm/1070mm (increased Z axis). Rapids X/Y/Z 40 m/min. Spindle speeds to 10,000 rpm. Spindle power 12/18.5 kW. Min/Max table to spindle nose 270mm/1070mm. Through spindle coolant with air blast. 48 capacity ATC. Renishaw TS27 Tool Sensor. Swarf management system (drag type) with lowered exit height. Fully interlocking doors.

Maximum swing 525mm dia. Maximum Cutting Diameter 356mm. Maximum Cutting Length 483mm.Bar capacity 51mm.10 station turret. Spindle speed 4,800 rpm. Spindle nose A2-6. Spindle power  16 kW. X travel 203mm. Z travel 508mm. Tailstock. Toolsetter. Swarf conveyor. Parts catcher. Rigid tapping. 3D Graphics. Machine complete with 3 jaw 200mm dia. powered chuck. Turret tooling. Bar puller. Coolant. Machine dimensions L x W x H. 2950mm x 2300mm x 2032mm. Approx weight 3700kgs.

12 Tool Turret. Spindle Speeds upto 6000rpm. Machine dimensions L x W x H. 3150mm x 1450mm x 1900mm. Approx. weight 3000kgs. Serial No: NJ-0029

Diameters 5mm - 180mm. Belt Size 10mm-100mm x 3500mm - 4000mm. Machine dimensions L x W X H 2600mm x 1300mm x 2000mm. Approx. weight 500kgs.

Working Capacity (mm) 40mm -114mm dia. Feeding Speed 0-3 metres/min. Polishing Wheels Speed up to 35 metres/sec. Polishing Wheels Dimensions (3x) (2x) 180mm-240mm dia. Polishing Wheels Motor (kW) 5,5. Wheel Motor (kW) 0,37. Consumption 22 amp. MP100 round tube machine mirror polishes round tubes, straight or curved. Three planetary polishing wheels rotate around the tube making high pressure and delivering a high gloss mirror polishing. The machine features brushes pressure control by foot pedal. This enables the operator to control the applied force during tube polishing operation. The automatic feeding system transports straight tubes safely through the polishing units, enabling a consistent and high mirror polishing quality. Machine Dimensions L x W x H 1250mm x1250mm x1550mm. Weight approx 420kgs.

1828mm between Centres. 406mm Swing / 203mm Centre. Wheelhead Speed 1420rpm. Max. Dia of Wheel 304mm. Machine Dimensions L x W x H 4200mm x 1950mm x 1800mm. Weight approx. 4500kgs. Serial No 33708

1066mm between Centres. 431mm Swing over Bed. Spindle Bore 75mm. Spindle Speeds 20-1600rpm. Machine Dimensions L x W x H 2500mm x 1150mm x 1450mm. Weight approx. 2000kgs

1828mm between Centres. 90mm Spindle Bore. Spindle Speeds 7.5 - 600rpm. 4 Jaw Dia. Chuck 455mm. Machine Dimensions L x W x H 3700mm x 1250mm x 1400mm. Weight approx. 3750kgs

1065mm between Centres. 330mm Swing over Bed. Spindle Bore 42mm. Spindle Speeds 35-1400rpm. 3 Jaw dia. Chuck 250mm. Machine Dimensions L x W x H 2500mm x 1100mm x 1600mm. Weight approx. 2000kgs

610mm between Centres. 280mm Swing over Bed. 32mm Spindle Bore. Variable Spindle Speeds 40-2500rpm. 3 Jaw dia. Chuck 160mm. Machine Dimensions L x W x H 1650mm x 1000mm x 1500mm. Approx weight. 650kgs.

610mm between Centres. 305mm Swing over Bed. 32mm Spindle Bore. Spindle Speeds 45-1000rpm. 3 Jaw dia. Chuck 190mm. Machine Dimensions L x W x H 1650mm x 900mm x 1400mm. Approx weight. 650kgs.

Squaring Arm. Sheet Supports. Machine Dimensions L x W x H 3300mm x 1800mm x 1800mm. Weight approx. 4000kgs

Segmental Tooling. Sheet Supports. Dimensions L x W x H 4300mm x 700mm x 1950mm. Weight approx. 3000kgs
