Lot 1: CORREA FP30-30 CNC Gantry Mill with Heidenhain TNC426 Control. Year 2002
Table dimensions 3000mm x 1250 mm. Number of T slots 8. T slots dimensions 22 mm. X axis traverse 2500 mm. Y axis traverse 1800 mm. Distance between columns 1680 mm. Z axis traverse 800 mm. Head Type Standard vertical spindle. Tool clamping system Hydraulic. Spindle Taper ISO 50. Speed Range 20-2000 rpm. Spindle power 22 kW. Feedrates 2-5000mm/min. Rapids 15000/12000 mm/min. Maximum weight on table 10,000 kg. External Guarding.Universal Milling Head. Coolant. Manual Toolchange. Machine dimensions 7300mm x 2690mm x 3400mm. Machine Weight 21,500 kg.
Lot 1: 3 tonne Overhead Crane with Crane Rail and 10 x Stanchions
Single Beam KONE Hoist Type Overhead Crane. 3tonne Capacity.
Year of Manufacture 2017
24ft span from centre wheel to centre wheel
Total length 25ft
Total width 10ft
Complete with 10 x Steel Stanchions and Rail
Lot 1: DOOSAN VT1100M Turning Centre with Fanuc 0iTF Control. Year 2023
Swing over bed 1270mm. Swing over saddle 1000mm. Maximum turning
diameter 1100mm. Maximum turning length 960mm. Maximum workpiece
weight (incl. chuck) 2,200kg. Spindle nose 702-4-NO.15. Spindle max
power 65 / 55 / 45kW. Spindle max torque 7,552Nm. Spindle speed
maximum 850rpm. Integral box guideway construction. X axis travel
580mm. Z axis travel 1,000mm. C axis travel 360deg. X axis rapid
traverse 20m/min. Z axis rapid traverse 20m/min. C axis rapid
traverse 14r/min. Type BMT85P. Number of stations 12. OD tool size
32mm square. Boring bar size 80mm diameter. Rotary tool power
7.5/11.0kW. Rotary tool speed 3000rpm. Rotary tool collet size ER50
(6-32mm diameter). Power requirements 98.77kVA.
Additional Accessories
Swarf Conveyor MH500 type (rear exit). Swarf bin. FSE 70 bar NOP
pump upgrade for switchable duty 3 pressures: 20, 40 and 70 bar
(back pressure) via M code. Coolant chiller. Operator working
platform. Coolant wash gun. Renishaw OLP40 inspection probe.
Filtermist FX7002F oil mist separator with F Monitor 2.
HC40G Samchully Closed Centre Chuck including 1 set of hard jaws
& 1 set of soft jaws. 2 off Face type toolholder (R78935). 2
off Cross type toolholder (R78756A).
Compete with a selection of 8 x unused live tooling
Dimensions L x W x H 2830mm x 3305mm x 4012mm. Weight
22,550kg.
550 Cutting Hours
Lot 3: XYZ 200TC CNC Lathe with Siemens 810D CNC Control. Barfeed and Swarf Conveyor
Maximum swing 420mm. Maximum turned dia. 200mm. Maximum turned length 550mm. Spindle bore 62mm. Bar capacity 52mm. Spindle speed 4800 rpm. 12 station turret (VDI). Spindle power 14.9kW. Fitted with Hydraulic 200mm dia. 3 jaw chuck. Tool Setting Arm. Swarf Conveyor. Remote Electronic Handwheel. Multifeed Barfeed. Hydraulic Tailstock. Siemens 810D CNC Control. Weight 4100kg
Lot 4: HAAS TM3P Vertical Machining Centre with Haas Control. Year 2015
Table Size 368 x 1467mm. Travels X/Y/Z 1016 x 508 x 406mm.
Maximum workpiece weight 454Kg. Maximum cutting feedrate
10.2m/minute. Rapid feedrates 10.2m/minute. Min – max height
under spindle: 102 – 508mm. Spindle motor power 5.6kW.
Spindle speed 6000rpm. Maximum tool diameter 89mm. Maximum tool
weight 5.4Kg. Tool change capacity 10 Stations. Tool change time
(chip to chip) 6.5 Seconds. Tool Size BT40. Current Software
Version M18.23A. Compensation tables. Intuitive Programming
Systems. Rigid Tapping. Spindle Hours 3970. Machine dimensions L x
W x H 3470 x 2457 x 2616mm
Weight 2800Kg
Lot 5: XYZ Mini Mill Vertical Machining Centre with Fanuc 0i-MB Control. Year 2005
Table size 610 x 370mm. T slot size 16mm. Max loading capacity 320Kg. Travels X/Y/Z 560/400/500mm. Distance from spindle nose to working table surface 100 – 600mm. Distance from spindle centre to main column 440mm. Spindle taper BT40. Spindle Speed 60 – 8000RPM. Feed rate X/Y/Z 1 – 10000mm/min. Rapid traverse rate X/Y/Z 20000mm/min. Tool magazine capacity 16. Max tool weight 8Kg. Spindle drive motor 10HP. Coolant 1/2Hp. Complete with FX4002 Filtermist. Dimensions 2400 x 1900 x 2450mm. Approx weight 2700Kg.
Lot 8: DAEWOO Puma CT250 CNC Lathe with Fanuc 21i-T. Swarf Conveyor. Year 2002
Swing over bed 570mm. Turning dia. 420mm. Maximum turning length 650mm. Spindle speeds 3500 rpm. Machine complete 3 jaw powered chuck. 10 station turret. Tailstock. Swarf conveyor. Swarf Bin. Toolsetter. Fanuc 21i-T Control.
Lot 12: VICTOR TNS-1A CNC Lathe with Fanuc 10T-A Control. Year 1985
12 Tool Turret. Spindle Speeds upto 6000rpm. Machine dimensions L x W x H. 3150mm x 1450mm x 1900mm. Approx. weight 3000kgs. Serial No: NJ-0029
Lot 13: LOESER KS-100 Belt Grinding Machine with BA attachment for Centreless Circular Grinding. Year 2001
Diameters 5mm - 180mm. Belt Size 10mm-100mm x 3500mm - 4000mm. Machine dimensions L x W X H 2600mm x 1300mm x 2000mm. Approx. weight 500kgs.
Lot 15: CHURCHILL 72" x 16" (1828mm x 406mm) Cylindrical Grinder with Internal Attachment
1828mm between Centres. 406mm Swing / 203mm Centre. Wheelhead Speed 1420rpm. Max. Dia of Wheel 304mm. Machine Dimensions L x W x H 4200mm x 1950mm x 1800mm. Weight approx. 4500kgs. Serial No 33708
Lot 16: COLCHESTER MASCOT 1600 42" x 17" (1066mm x 431mm) Gap Bed Lathe
1066mm between Centres. 431mm Swing over Bed. Spindle Bore 75mm. Spindle Speeds 20-1600rpm. Machine Dimensions L x W x H 2500mm x 1150mm x 1450mm. Weight approx. 2000kgs
Lot 17: DEAN SMITH GRACE 21" x 72" (533mm x 1828mm) Gap Bed Lathe
1828mm between Centres. 90mm Spindle Bore. Spindle Speeds 7.5 - 600rpm. 4 Jaw Dia. Chuck 455mm. Machine Dimensions L x W x H 3700mm x 1250mm x 1400mm. Weight approx. 3750kgs
